[DAIWA] Genuine Spare Parts for 20 SALTIGA 10000-H Product code: 00065004 **Back-order (Shipping in 3-4 weeks after receiving order)

[DAIWA] Genuine Spare Parts for 20 SALTIGA 10000-H Product code: 00065004 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 - US$199.43 [Regular Price: US$1.10 - US$284.90]

Prices vary according to options.

View availability
Part Number:
Quantity:
Return & Exchange Policy
Contact Us

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.

- We don’t accept order cancellations, changes, or refunds after an order unless the products you ordered are not available because SHIMANO/DAIWA Japan doesn’t accept our cancellations.



*Please make sure to read about the conditions before you order.


- Genuine Spool Purchase

* If you just want the genuine spool (No.9 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/product/4737

　Reel Part's Schematic Diagram



No. Part Name Part Code Price (USD)
1 DRAG KNOB 6J900501 181.50
2 CLICK GEAR PLATE SC 6M042301 12.10
3 CLICK GEAR PLATE 6J900301 4.40
4 CLICK GEAR PIN 6J916501 2.20
5 CLICK GEAR 6J900201 4.40
6 SPOOL BEARING RING 6J899901 2.20
7 SPOOL BALL BEARING (A) 6J899801 18.70
8 SPOOL BALL BEARING (A) COLLAR 6J899701 6.60
9 DRAG W SET (7 PCS) 6M146201 77.00
10 DRAG LIP W 6J899601 2.20
11 DRAG DISC W 6J899501 2.20
12 SPOOL BALL BEARING (B) 6J899301 8.80
13 SPOOL (2-13) 6J966401 284.90
14 SPOOL W (0.5) 6J898601 1.10
15 SPOOL PLATE PACKING (A) 6J898501 2.20
16 SPOOL PLATE 6J898301 4.40
17 SPOOL PLATE PACKING (B) 6J898401 2.20
18 ROTOR COVER 6J898201 8.80
19 ROTOR COVER SC 6H401201 2.20
20 ROTOR NUT PACKING 6J898101 2.20
21 ROTOR NUT BEARING W 6G522103 1.10
22 ROTOR NUT BALL BEARING 6G467102 8.80
23 ROTOR NUT 6H504801 3.30
24 ROTOR NUT COLLAR 6J898001 3.30
25 ROTOR NUT W 6J916401 1.10
26 ROTOR NUT O-RING 6H501001 1.10
27 ROTOR *Repair only (cannot be ordered) 6J896201 115.50
28 BAIL SHAFT (A) SP 6J896401 2.20
29 BAIL SHAFT (A) W 6J919501 1.10
30 BAIL SHAFT (A) 6J896301 3.30
31 BAIL SHAFT (B) SP HOLDER 6J322001 2.20
32 BAIL SHAFT (B) SP 6J321901 2.20
33 BAIL SHAFT (B) PLATE 6J916001 2.20
34 BAIL SHAFT (B) 6J321701 2.20
35 BAIL SHAFT (B) COLLAR 6J916101 2.20
36 BAIL HOLDER PLATE 6J897401 2.20
37 BAIL *Repair only (cannot be ordered) 6J896901 108.90
38 ROLLER W 6E096501 1.10
39 ROLLER MAG COLLAR O-RING 6J916201 1.10
40 ROLLER MAG COLLAR (A) *Repair only (cannot be ordered) 6J897501 12.10
41 ROLLER BALL BEARING (A) 6H738904 15.40
42 LINE ROLLER *Repair only (cannot be ordered) 6J897801 8.80
43 ROLLER BALL BEARING (B) 6H738904 15.40
44 ROLLER MAG COLLAR (B) *Repair only (cannot be ordered) 6J897901 12.10
45 ROLLER MAG COLLAR O-RING 6J916201 1.10
46 ROLLER COLLAR 6J916301 2.20
47 ARM LEVER PLATE 6J896601 2.20
48 ARM LEVER 6M030501 39.60
49 ARM LEVER SC 6J896701 2.20
50 ROLLER SC 6H504701 2.20
51 ARM LEVER COVER 6J896801 6.60
52 ARM LEVER COVER SC 6H401201 2.20
53 CLUTCH RING O-RING 6H255001 1.10
54 CLUTCH RING *Repair only (cannot be ordered) 6J896001 18.70
55 INFINITE COVER *Repair only (cannot be ordered) 6J896101 36.30
56 INFINITE COVER O-RING 6H629701 1.10
57 MAG SHIELD PLATE *Repair only (cannot be ordered) 6H535301 23.10
58 MAG SHIELD PLATE O-RING 6H502601 1.10
59 ONE-WAY CLUTCH *Repair only (cannot be ordered) 6F765401 36.30
60 ONE-WAY CLUTCH W 6G158101 2.20
61 PINION BEARING (A) PLATE 6J895801 3.30
62 PINION BEARING (A) PLATE SC 6F206902 2.20
63 PINION BALL BEARING (A) 66355001 8.80
64 PINION BALL BEARING (A) COLLAR 6J895701 2.20
65 RATCHET 6E262701 2.20
66 RATCHET W 6G613404 1.10
67 PINION + DRIVE GEAR SET *Repair only (cannot be ordered) 6Z025448 132.00
68 PINION BEARING (B) SPRING W 6G578502 1.10
69 PINION BEARING (B) W 6H411402 1.10
70 PINION BALL BEARING (B) 6H739703 8.80
71 PINION BALL BEARING (B) COLLAR 6J895101 3.30
72 BODY *Repair only (cannot be ordered) 6J893201 105.60
73 OSCILLATING POST 6J894601 2.20
74 MAIN SHAFT (74-76) *Repair only (cannot be ordered) 6J894201 30.80
75 OSCILLATING SLIDER COLLAR SC 6M067801 2.20
76 OSCILLATING SLIDER COLLAR 6J894401 2.20
77 REAR CAP PACKING 6J894701 3.30
78 REAR CAP *Repair only (cannot be ordered) 6J894801 36.30
79 REAR CAP SC (A) 6J894901 2.20
80 REAR CAP SC (B) 6J895001 4.40
81 OSCILLATING GEAR W 6J893601 1.10
82 OSCILLATING GEAR *Repair only (cannot be ordered) 6J893701 7.70
83 OSCILLATING GEAR O-RING 6J037601 1.10
84 OSCILLATING GEAR BEARING W 6G522101 1.10
85 OSCILLATING GEAR BALL BEARING 6G467102 8.80
86 OSCILLATING GEAR SC 6H272202 2.20
87 STOPPER COLLAR 6H243301 2.20
88 STOPPER 6M030301 3.30
89 STOPPER SC 63516401 2.20
90 STOPPER SP 6J895601 2.20
91 IDLE GEAR O-RING (A) 6G163201 1.10
92 IDLE GEAR O-RING (B) 61715202 1.10
93 IDLE GEAR 6J893801 22.00
94 IDLE GEAR O-RING (C) 6J185801 1.10
95 DRIVE GEAR O-RING 6G163201 1.10
96 COVER PLATE PIN O-RING 6B853101 1.10
97 COVER PLATE PIN 6J902801 2.20
98 DRIVE BALL BEARING O-RING 6J042501 1.10
99 DRIVE BALL BEARING (A) *Repair only (cannot be ordered) 6J042402 45.10
100 DRIVE BALL BEARING (A) W 6J893901 1.10
101 COVER PLATE O-RING 6J894101 1.10
102 COVER PLATE *Repair only (cannot be ordered) 6J894001 59.40
103 HANDLE CAP 6J902001 18.70
104 DRIVE BALL BEARING (B) *Repair only (cannot be ordered) 6J042402 45.10
105 DRIVE BALL BEARING (B) W 6G529501 1.10
106 DRIVE BALL BEARING (B) O-RING 6J042501 1.10
107 ENGINE PLATE O-RING 6J894101 1.10
108 ENGINE PLATE *Repair only (cannot be ordered) 6J895905 59.40
109 HANDLE 6J901301 242.00
111 ARM LEVER SC/W 6M050901 1.10
112 HOLDER PLATE SC/W 6M050901 1.10
113 REAR CAP SC (A) W 6E272501 1.10
114 CLUTCH RING W 63712821 1.10
200 NAMEPLATE *Repair only (cannot be ordered) 6J893510 3.30
201 HANDLE KNOB PACKING 6G223301 2.20
202 HANDLE KNOB W 63753005 1.10
203 HANDLE KNOB BALL BEARING 6G466205 15.40
204 HANDLE KNOB SHAFT 6M168001 18.70
205 HANDLE KNOB SC 6E454003 2.20
206 HANDLE KNOB O-RING 6G378001 1.10
207 HANDLE KNOB 6J902901 72.60
208 SPOOL W (0.8) 6J898602 1.10
209 SPOOL BAND 6X268103 15.40
