[SHIMANO] Genuine Spare Parts for 14 Scorpion 201 HG Product code: 032263 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 14 Scorpion 201 HG Product code: 032263 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 - US$47.36 [Regular Price: US$1.10 - US$67.65]

Prices vary according to options.

Part Number:
Quantity:

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.



- Genuine Spool Purchase

* If you just want the genuine spool (No.76 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/product/1974

 Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* As for the "30 / ROLLER CLUTCH" , they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
1 103EE FIXING BOLT 2.75
2 10Q5Q RETAINER 3.85
4 13MAA HANDLE CAP 3.85
5 103E9 FIXING BOLT 1.10
6 10PXY HANDLE GRIP BUSHING (B) 1.65
7 104FH WASHER 2.20
9 104VX BALL BEARING (4 X 7 X 2.5) 13.75
10 13HRE HANDLE 22.55
12 10KXV STAR DRAG CLICK PLATE 1.65
13 10J26 STAR DRAG CLICK PLATE 1.65
14 10BT0 CLICK PIN 1.65
15 10BT2 CLICK SPRING 1.65
17 10A70 STAR DRAG SPRING 2.75
19 10J1N STAR DRAG SPACER 1.65
20 10D60 MAIN GEAR WASHER (C) 1.65
21 13TXR MECHANICAL BRAKE KNOB 9.35
22 10896 MECHANICAL BRAKE WASHER 1.10
23 1085F MECHANICAL BRAKE WASHER 1.10
25 105C0 BALL BEARING (3 X 10 X 4) 13.75
26 10EYS BEARING SPACER 2.75
28 10MPT FIXING BOLT 1.10
30 10F5D ROLLER CLUTCH BEARING A-RB *Cannot be ordered 17.05
31 10CCN INNER TUBE 6.05
32 10D3H STAR DRAG PLATE 2.75
33 106XT STAR DRAG WASHER 6.05
35 10CHF STAR DRAG WASHER 6.05
36 109BB STOPPER GEAR 6.05
38 10HJG WORM SHAFT GEAR PINS 1.65
39 10J47 WORM SHAFT GEAR 2.75
40 10MT0 FIXING BOLT 1.10
41 109T0 MAIN GEAR SHAFT FIXING PLATE 2.75
42 10C47 MAIN GEAR SHAFT WASHER 1.10
43 105NK E TYPE RETAINING RING 2.5 1.10
45 10FJB LEVEL WINDING RECEIVER 1.65
46 10CFW ADJUSTMENT WASHER SET 1.10
47 10FFZ WORM SHAFT PIN 2.75
48 108WQ O-RING 1.65
49 10NVQ LEVEL WINDING ASSEMBLY 11.55
50 10FNV WORM SHAFT GEAR 2.75
51 10AEZ WORM SHAFT PIN 1.10
52 104SN WORM SHAFT 6.05
53 10NFQ LEVEL WINDING PIPE 1.65
54 103DC FIXING BOLT 1.10
56 10487 CLUTCH YOKE SPRING 1.10
58 10LVE FIXING BOLT 1.10
59 10F3X CLUTCH CAM PUSH PLATE 3.85
64 103C0 FIXING BOLT 1.10
65 10EX8 BALL BEARING (8 X 12 X 3.5) 13.75
67 105NB E TYPE STOP RING 1.5 1.10
71 10QSE LEVEL WINDING GUIDE 1.65
72 10FJZ WASHER 1.10
73 105NC E TYPE RETAINING RING 2 1.10
74 108SK WASHER 1.10
75 108PY FRAME ATTACHMENT WASHER 1.65
76 13GHJ SPOOL ASSEMBLY 56.10
77 1046G BRAKE SHOE (M) RED 1.10
78 10GEW BEARING RETAINING CLAMP 1.10
79 1057S SPOOL SHAFT CONTACT (B) 1.10
80 10EXQ BRAKE PIPE GEAR 13.75
81 103N4 FIXING BOLT 1.10
83 104MZ BODY B CAM LEVER ADJUSTMENT WASHER 1.65
85 10KNG DAMPER SPRING 1.10
86 103LE FIXING BOLT 1.10
87 10GFB CAM LEVER ADJUSTMENT WASHER 1.10
89 103L7 FIXING BOLT 1.10
90 10CLF INTERMEDIATE GEAR 1.65
92 105BP BALL BEARING (5 X 9 X 3) 13.75
93 10JDY WORM SHAFT GEAR SPRING 1.65
94 10TMT MECHANICAL BRAKE YURUMI STOP SPRING 1.65
95 10LCT FIXING BOLT 1.65
141 10FFD HANDLE FIXING NUT 2.75
142 13UZZ HANDLE KNOB 11.55
143 13HY7 HANDLE ASSEMBLY 67.65
144 10AU0 STAR DRAG 17.05
145 10A3U STAR DRAG FIXING NUT 3.85
148 1058M DRIVE GEAR SHAFT 11.55
149 13S6W LEVEL WINDING GUARD 6.05
151 1046W CLUTCH YOKE 1.65
152 10K0P CLUTCH CAM 2.75
153 10MQM CLUTCH CLAW 3.85
154 10QGJ CLUTCH PLATE 4.95
155 10BVM BODY A SEAT 3.85
156 13FWW FRAME 50.60
157 1096T CLUTCH LEVER RECEIVER (B) 1.65
158 10CDM CLUTCH LEVER 6.05
159 10FXC FRAME B RECEIVER ASSEMBLY 13.75
160 10BAL BODY B CAM LEVER 2.75
161 10AZC BR KNOB 3.85
162 13R3N BODY B ASSEMBLY 11.55
163 104CQ CLUTCH CLAW SPRING 1.65
171 13TQW BODY A 22.55
172 10CME DRIVE GEAR 22.55
173 10CRY PINION GEAR 11.55
BNKI 13WKD EXPLODED VIEW (ACCESSORIES) 1.65
OIL1 10LQ0 B-100 OIL (4.5G) 3.85
TRST 13VN4 INSTRUCTION MANUAL (ACCESSORY) 1.65
