[SHIMANO] Genuine Spare Parts for 15 TWIN POWER 3000HGM Product Code: 034045 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 15 TWIN POWER 3000HGM Product Code: 034045 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 - US$72.38 [Regular Price: US$1.10 - US$103.40]

Prices vary according to options.

View availability
Part Number:
Quantity:
Return & Exchange Policy
Contact Us

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
1 10GZZ DRAG KNOB ASSEMBLY 17.05
2 10B8J STOPPER SPRING 1.65
4 102ZP DRAG WASHER (A) 1.65
5 10GEW BEARING STOPPER 1.10
6 104JT BALL BEARING (6 X 10 X 3) 13.75
7 10388 SPOOL PIN 1.65
8 10BQE SPOOL PIN SPRING 1.65
9 10A6F FIXING BOLT 1.65
11 10BU7 SPOOL WASHER SET 1.10
12 10PN2 SET SCREW 1.65
13 10LTR SPOOL SHAFT BEARING GUIDE 6.05
14 104PP BALL BEARING (7 X 11 X 3) 13.75
15 102VD WASHER 1.10
16 107V0 DRAG CLICK RATCHET 2.75
17 103PC SPOOL RECEIVER 1.65
18 107V3 RATCHET SPRING 1.65
19 13JV2 FIXING BOLT 1.10
20 1076P RETAINER 2.75
21 107L3 ROTOR BEARING SEAL 2.75
22 1067X ROTOR NUT 3.85
23 10GAR LINE ROLLER BEARING COLLAR 2.75
24 10N6E LINE ROLLER (WITH BEARING) 22.55
25 10HWT LINE ROLLER RECEIVER 1.65
26 10CH0 BAIL TRIP LEVER CLICK SPRING 1.65
27 10CHA BAIL TRIP LEVER CLICK PIN 1.65
28 105YZ ARM SPRING GUIDE (A) 3.85
29 1064R ARM SPRING GUIDE (A) COLLAR 1.65
30 105R5 ARM CAM SPRING 1.65
31 106P1 BAIL TRIP LEVER 2.75
32 10KLX ARM CAM 6.05
33 10PS3 FIXING BOLT 1.10
34 10PS4 FIXING BOLT 1.10
35 10PS6 FIXING BOLT 1.10
36 108C0 ARM CAM SPRING COVER 6.05
38 10Q1X ROTOR 22.55
39 103N4 FIXING BOLT 1.10
40 10MNP BALE MOUNTING BRACKET COVER 11.55
41 103N8 FIXING BOLT 1.10
42 10L01 ARM FIXING SHAFT 2.75
43 103AL BALE ASSEMBLY 34.10
45 10MTE FIXING BOLT 1.10
46 10L61 ROLLER CLUTCH COVER PLATE 1.65
49 10MLT O-RING 3.85
50 107S5 ROLLER CLUTCH INNER COLLAR 2.75
51 10H4G ROLLER CLUTCH INNER COLLAR 1.65
52 10ML6 FIXING BOLT 1.65
53 10594 BEARING PUSH PLATE 1.65
55 10JDC ADJUSTMENT WASHER SET 1.10
61 107DZ BAIL TRIP STRIKE 1.65
62 104FU FRICTION RING 3.85
65 106M8 WORM SHAFT BUSHING (FRONT) 2.75
69 1055G FIXING BOLT 1.65
70 104JD BALL BEARING (7 X 13 X 4) 13.75
71 10CBC COVER FLANGE SEAL 2.75
73 10M2B FIXING BOLT 1.10
76 10PXU HANDLE SHAFT SEAL 2.75
77 10PQJ HANDLE SHAFT FLANGE (B) 8.25
78 10C4J HANDLE SHAFT FLANGE 14.85
80 104VX BALL BEARING (4 X 7 X 2.5) 13.75
82 10G8G WASHER 1.10
83 103E9 FIXING BOLT 1.10
88 10RKQ WASHER 2.20
92 10PRY FIXING BOLT 1.10
94 10AYN BODY GUARD COLLAR 2.75
96 106CM CROSS GEAR BUSH (FRONT) 1.65
97 10J7K WASHER 1.10
99 10JAB O-RING 1.65
105 10N18 HANDLE SCREW CAP 11.55
106 107AC ARM CAM SPRING SEAT 2.75
107 10HVD WASHER 1.10
111 10SDC ROLLER CLUTCH SEAL ASSEMBLY 11.55
112 10DG6 ROLLER CLUTCH ASSEMBLY 12.65
123 103WG HANDLE 39.60
131 10JJV OVAL WASHERS 6.05
133 10BBQ OVAL WASHER 2.75
134 10C13 DRAG WASHER (B) 1.65
136 1040S HANDLE NIPPLE 17.05
137 108X1 HANDLE SAW BLADE NAMEPLATE 3.85
138 103NH FIXING BOLT 1.10
210 108W6 O-RING 1.65
211 10J6G PINION GEAR SPACER 1.65
212 104JU BALL BEARING (6 X 10 X 3) 13.75
213 10CLB INTERMEDIATE GEAR SHAFT 3.85
214 10AYT BODY FLANGE SEAL 2.75
215 10LPQ FIXING BOLT 1.10
216 10HEV WORM SHAFT GEAR 6.05
217 10J3P FRICTION RING SPACER 2.75
219 104HU COVER 39.60
224 10MT4 FIXING BOLT 1.10
225 10HAH WORM SHAFT PIN PUSH PLATE 1.65
226 10JXV WORM SHAFT PIN COLLAR 2.75
227 106VM WORM SHAFT PIN 4.95
229 10NL5 BODY GUARD 11.55
230 107HK BODY COVER 1.65
231 10ATE WORM SHAFT COVER 1.65
233 1035T SLIDER GUIDE (A) 2.75
234 104MG SLIDER GUIDE (B) 2.75
235 106VU INTERMEDIATE GEAR (S) 8.25
239 104Q6 BALL BEARING (7 X 14 X 5) 13.75
272 10ELY DRIVE GEAR ASSEMBLY 28.05
273 10CQJ INTERMEDIATE GEAR (L) 9.35
312 13CBE SPOOL ASSEMBLY 103.40
314 13D9Z MAIN SHAFT ASSEMBLY 28.05
315 13M1X WORM SHAFT 11.55
316 13D9W BODY 78.65
317 10BE6 EAR WASHERS 6.05
318 13EM6 HANDLE ASSEMBLY 101.20
319 13AY8 PINION GEAR 20.35
*F01 13QN1 REEL BAG 3.85
BNKI 13R0J EXPLODED VIEW (ACCESSORIES) 1.65
ITOS 13QPZ STOPPER SEAL 1.65
MH01 13NEW NAMEPLATE ON THE BACK OF THE FOOT 2.75
TRST 13PMG INSTRUCTION MANUAL (ACCESSORY) 1.65
