Notes
* Max drag is the drag force at the FULL position when the preset knob is tightened to just before the spool free position is engaged.


| Spare Spools, Bearings & Other Custom Parts for TALICA Series - Genuine Parts & Custom Parts Available Here!






PUSH THE LIMITS

Designed for big-game power fishing across a wide range of situations - from offshore live bait and drift fishing to rocky shore fishing and trolling - the lever drag reel TALICA proves its true worth when it matters most.
Built around the HAGANE concept with an ultra-precision one-piece frame and S Compact Body for maximum rigidity, it also features the trusted waterproof mechanism X-Protect and a carbon cross washer with built-in waterproof performance in the drag section.
The 2-speed gear, which can be switched instantly during a fight, delivers both fast line pickup and powerful cranking force - an indispensable function.
The Infinity Drive-equipped double drag structure achieves even higher drag performance than the previous model while reducing handle rotation resistance under high drag by more than 30%.
The low gear ratio has also been lowered further to provide the torque needed to powerfully lift large fish.
It also comes equipped with a light line cam that enables smooth drag changes through lever operation.
The new TALICA, combining compact yet robust construction with reassuringly high performance, pushes the limits further and breaks through barriers once thought impossible.


A Full Lineup of 6 Models - Choose the Right One for the Right Situation.





The lineup now includes 6 models with 3 newly added sizes.
Example applications: the 12II/16II are ideal for live bait and drop fishing from rocks or boats, as well as live bait fishing for yellowfin tuna up to 50 kg.
The 20II is suited for live bait fishing for grouper and large amberjack, the 25II covers live bait and float fishing for yellowfin tuna over 100 kg and bluefin tuna, and the 40II & 50II can handle bluefin tuna and marlin over 200 kg with ease.
The optimal model can be selected by considering target species, water depth, line class, and other conditions.


Infinity Drive Double Drag Structure - Combining High Drag Performance With Light Retrieve.



For big-game reels, reliable drag performance is just as important as a rigid body.
Lever drag systems offer many advantages - they deliver high and stable drag force while allowing quick and precise adjustment - but they also had the drawback that heavier drag settings made the handle feel heavier to turn.
TALICA overcomes this weakness by incorporating Infinity Drive.
The double drag structure achieves even higher drag values than the previous model, while handle rotation under high drag is more than 30% lighter compared to conventional reels of the same size.


Effortless Fighting Even Against Large Fish. Instant Gear Shifting With 2-Speed Gear.



TALICA's 2-speed gear system allows instant gear changes with a single button press, even during actual fishing.
Switch smoothly and easily from high gear for fast line retrieval to low gear for powerful cranking during the fight.
On sizes 20II and above, the low gear ratio has been lowered even further for even stronger winding power.


New Sizes Added - Handle Knobs Matched to Each Application.



Newly added 12/16 and 40 sizes that were not available before.
The expanded lineup now covers a broader range of big-game fishing applications.
Handle knobs: Egg type (Knob Type B) for 12II/16II, Egg type for 20II, newly adopted T type (Knob Type D) for 25II, and T type (dedicated knob) for 40II/50II.
Selecting the optimal shape for each size and application enables stress-free performance even in hard battles with large fish.


Light Line Cam for Nylon Line Included.



A light line cam designed for nylon line is included.
Using this cam sets the drag value at the same lever position lower than with the standard cam.
Customize it according to your purpose and experience level.






Drag Curve Comparison








| Features



Clicker
Equipped with a clicker to audibly signal line release.




Rod Clamp Included
Includes a clamp for secure attachment to the reel seat.
Also helps prevent the reel seat from loosening.
* Clamp color and shape vary depending on model size.




Harness Lug Included (#20 and Above)
Includes a harness lug for harness use.
Supports fights against exceptionally large fish.


TECHNOLOGY

| HAGANE

Pursuing a Retrieve Feel That Never Changes



Reliable enough to be trusted even in harsh conditions.
A precise and refined retrieve feel, confident operability that stimulates the senses, and winding power beyond imagination.
The relentless pursuit of a reel that anglers can truly use to the fullest gave birth to HAGANE Gear and HAGANE Body - and this has become SHIMANO's conviction.
All for the angler.
#baitcasting-reel #HAGANE #HAGANE-Gear #HAGANE-Body

HAGANE - SHIMANO's Conviction



SHIMANO's reel design philosophy aimed at “a retrieve feel that never changes.”
That is “HAGANE.”
Through precision cold forging and other proprietary metal processing technologies refined to the extreme, SHIMANO pursues reels that only SHIMANO can create.
SHIMANO reels backed by the “HAGANE” philosophy offer inspiring smoothness and overwhelming strength, and continue to be loved by many anglers for years to come.
Products that reveal their true value the more they are used are the embodiment of SHIMANO's unwavering resolve and promise.

SHIMANO Technology That Realizes the HAGANE Philosophy.



Supporting reel manufacturing based on the “HAGANE” philosophy are SHIMANO's proprietary metal processing technologies cultivated over many years.
These include “HAGANE Gear,” which creates overwhelming strength and durability from tooth tip to root for smooth retrieve, and the high-rigidity “HAGANE Body,” which suppresses twisting and flexing during retrieve, protects the reel interior from unexpected impacts, and enables smooth reeling.

The Symbol of SHIMANO Metal Processing Technology.
Precision Cold Forging “HAGANE Gear.”



Unlike hot forging, SHIMANO's precision cold forging technology - “HAGANE Gear” - achieves superior precision and strength by applying pressure to metal at room temperature.
“HAGANE Gear” is formed by compressing a lump of metal with approximately 200 tons of force.
No cutting is performed on the tooth surface at all; instead, pressing creates high-precision gears with micron-level accuracy in a single operation - a technology unrivaled in the world.
The quality is truly worthy of the name “forged metal.”

Forging a Lump of Metal Into a Precision Gear



- High Density: When the cross-section of a “HAGANE Gear” produced by precision cold forging is compared to a cast (die-cast) gear, the difference is clear.
In casting, where material is melted and poured into a mold, air bubbles and foreign matter tend to mix in, as shown by the black dots in the image.
Precision cold forging, on the other hand, has a high crystal density with no voids.
This results in a tougher, more durable gear.



- High Hardness: In precision cold forging, where no cutting (machining) is performed on the gear tooth surface, the metal flow (flow of the metal structure) is not severed.
A gear whose metal structure flows along its shape is highly resistant to impact and extremely difficult to break.



- High Lubricity: Gears made by cutting have fine scratches and protrusions on the surface, causing localized fatigue.
However, “HAGANE Gear” has almost no irregularities on the tooth surface, so even after repeated reeling over many fishing trips, noise is unlikely to occur and smooth retrieve is maintained.

Protecting Gears and Rotational Performance From Load and Impact.
High-Rigidity Metal “HAGANE Body.”



The “HAGANE Body” uses high-rigidity metals such as aluminum and magnesium.
While achieving the ultimate in weight reduction, it suppresses reel flex, distortion, and twisting to enable smooth reeling with minimal power loss.
Its high rigidity also protects precise gear meshing from impact, maintaining the retrieve feel.
The metal body, refined for function, also carries a dignified beauty.

SHIMANO's Conviction for All Anglers



“HAGANE,” as advocated by SHIMANO, is the design philosophy of creating reels that can truly be pushed to the limit, combining toughness with precision and advanced technology.
This pursuit gives rise to durable gears (“HAGANE Gear”) and the high-rigidity body that firmly supports them (“HAGANE Body”) - world-class strength and smoothness are the answer.
The true value of “HAGANE” becomes more apparent the more you use it. Carrying the message of strength, “HAGANE” is now delivered to anglers everywhere.


| Infinity Drive

Dramatically Reduced Rotational Resistance.
Infinity Drive Challenges the Impossible Through a New Approach.



A new mechanism developed by SHIMANO to achieve more powerful yet lighter winding.
Of the two grease bearings supporting the pinion gear, the spool-side bearing with higher rotational resistance is no longer used for support.
Instead, the structure has been redesigned so that the pinion gear is supported internally by the spool shaft.
In addition, support distance, wall thickness, and other factors have been thoroughly optimized to also achieve high support rigidity.
Rotational resistance in the gear section has been greatly reduced without sacrificing gear strength.


| X-Protect

An Impregnable Waterproofing System.



A water barrier and special water-repellent grease work together to firmly guard against water intrusion into the spool-side bearing of the drive gear shaft.


| S Compact Body



By making the palming side smaller in diameter than the handle side, it creates a grip feel as if holding a reel one size smaller.
This improves palmability.


| S A-RB

Bearings That Resist Rust



SHIMANO's “S A-RB” greatly improves corrosion resistance on the metal surface by applying a special anti-rust treatment to the bearings.
In addition, the shield helps reduce the intrusion of foreign matter such as sand.
#baitcasting-reel #double-axis-single-axis #S-A-RB

The Role of Bearings in a Reel



“Bearings” are components that allow the shaft inside a machine to rotate smoothly, and they are essential for improving reel performance.
They also play an important role in casting ease and sensitivity during retrieve.
However, when saltwater, rain, sand, or salt enters the bearings, rust develops and the smoothness of the retrieve is lost.
To prevent this, reel bearings are often made of stainless steel or treated with special coatings.

Greatly Improved Rust Resistance

SHIMANO's “S A-RB” creates a physical shield (guard) on the side of the bearing to help block rust, and also applies a special treatment (anti-rust treatment) to resist corrosion.
Even when saltwater enters, the metal surface resists rust and corrosion.
As a result, the bearings last longer and comfortably support the angler's fishing life.
