【SHIMANO】 Level Wind Cap 【ALD】 BLACK

【SHIMANO】 Level Wind Cap 【ALD】 BLACK

Our Selling Price: US$7.26

Retail Price: US$8.28

Not available

|Description of the product

※The screw is used with 1.5mm hex wrench.

※Can be used for both left and right handles.

※In order to attach the parts, you need to disassemble the gear box.

|Corresponding Models

〜 JAPAN MODEL 〜

■12 ALDEBARAN BFS XG
■09 ALDEBARAN Mg/Mg7
■08 Metanium MgDC/MgDC7
■07 Metanium Mg/Mg7
■12 ANTARES & ANTARES HG
■06 ANTARES AR/DC/DC7
■12 EXSENCE DC
■CALCUTTA CONQUEST 50
■CALCUTTA CONQUEST 50S

〜 USA & EUROPA MODEL 〜

■CORE (ALDEBARAN & Metanium Type)

|Instruction Manual for Metanium Mg/MgDC.

Aldebaran Metanium Level Wind Cap

Please use a small precision screw driver to remove the level wind cap.

Aldebaran Metanium Level Wind Cap

After removing the stock cap,there will be a washer inside of it.
Please use that same washer when applying our custom cap.

Aldebaran Metanium Level Wind Cap

Now, simply place that washer back on and apply our custom cap and your finished.
|Instruction Manual for Aldebaran Mg.

Aldebaran Metanium Level Wind Cap

First open open the side plate cover and remove the small screw attaching the front cover.

Aldebaran Metanium Level Wind Cap
Aldebaran Metanium Level Wind Cap

Next, first remove the handle and then remove the side cover screws.

Aldebaran Metanium Level Wind Cap

Then you can remove the front and side covers from your reel.
Please do not turn your reel over after removing the cover as small parts may fall off and be lost.

Aldebaran Metanium Level Wind Cap

Next, you may remove the stock level wind cap from your reel.

Aldebaran Metanium Level Wind Cap

After removing the stock cap,there will be a washer inside of it.
Please use that same washer when applying our custom cap.
Please use the below photo as a reference point.
Most of shimano's reels maintenance can be done using the same fashion.

Aldebaran Metanium Level Wind Cap

Make sure you have securely fastened the inner tube to the gear before attaching the side cover.

Aldebaran Metanium Level Wind Cap

Next, check to make sure that the drive gears metal washers face each other perfectly.

Aldebaran Metanium Level Wind Cap

When replacing the star drag washer,
make sure that the smooth side of the washer is facing outward towards the nut.
This step cannot be mistaken.

Aldebaran Metanium Level Wind Cap

Finally, when replacing the star drag,
make sure all parts are straightly aligned and finish the assembly.
