CONQUER THE IMPOSSIBLE

The STELLA SW, which has earned a solid track record both domestically and internationally, has undergone a model change featuring numerous new technologies.
Enhanced drag performance with XX Tough Drag, improved castability with Infinity Loop, greater gear strength and durability with Infinity Xross, and reduced line trouble with Anti-Twist Fin—all these advantages are now included.
Additionally, the reel has been fine-tuned in every detail, including the addition of waterproof seals to the handle knob and a larger drag knob.
The newly evolved STELLA SW is now ready to face big game head-on in saltwater scenarios.




XX TOUGH DRAG

Significant Advancements in Drag Durability



All drag components employ STELLA SW-exclusive carbon washers that are resistant to metal wear and abrasion.
In addition to the conventional lower drag washers, the spool structure has been enhanced to accommodate larger washers at the top as well.
This evolution increases drag durability.
Thanks to the improved drag structure and the synergy with the integrated Heat Sink Drag, heat-related drag power reduction is decreased by approximately 30% compared to previous models.
*8000 series is equipped with X Tough Drag.




Enhanced Heat Dissipation and Durability
Evolving Strategy for Targeting Big Game



“X Tough Drag” and “XX Tough Drag” are technologies that improve heat resistance and durability in the reel's drag system, refining smooth and stable drag performance.
These features are especially effective when fighting large fish such as GTs or tuna.




The Role and Importance of Drag

The drag system plays a vital role in reducing the load on the line and minimizing the risk of line breakage.
In particular, large fish like tuna run fast and far, prolonging the fight.
When hooked in areas with strong currents, the fish may run intensely, heating up the drag and causing performance to drop.
Therefore, high durability and effective heat dissipation in the drag system are essential for stopping big game without strain.




Smooth and Stable Drag Performance

“X Tough Drag” uses only metal and carbon for each washer within the drag system and supports the spool from both top and bottom.
This structure enhances both heat resistance and durability.

Not only does it withstand prolonged use, but it also responds smoothly to strong pulls from large fish, preventing line breakage and delivering reliable performance in various situations.

*X Tough Drag: 8000PG, 8000HG, 8000XG only




Further Evolution of Drag Durability

In 2025, “X Tough Drag” has evolved even further into the “XX Tough Drag.”
Each drag component uses carbon washers that are resistant to metal wear and abrasion.
The spool structure has been evolved to include large-diameter drag washers not only at the bottom but also at the top.
This advancement further enhances drag stability and durability, increasing resistance to heat degradation caused by continuous high-tension rotation.
You will truly feel the difference in demanding big game fishing where drag is frequently pulled.

*XX Tough Drag: 10000PG, 10000HG, 14000XG only


HEAT SINK DRAG



Let Them Run Wild, Stop Them Firmly—A Heat-Resistant Tough Drag You Can Trust.

The Heat Sink Drag is an evolution of the previous model’s X Tough Drag, which delivered overwhelming drag performance and durability, now even more resistant to heat.
The “Heat Sink Panel” disperses heat generated in the drag system outside of the spool, reducing drag power loss due to heat degradation.
In addition, the “Insulating Sheet” blocks heat from transferring to the spool winding area, successfully reducing its temperature rise.

*Heat Sink Drag: 10000PG, 10000HG, 14000XG only


INFINITYLOOP

An Oscillation System Thoughtfully Designed for SW Use



Infinity Loop improves casting distance, casting feel, and drag smoothness by intricately and evenly winding the line.
It features optimal winding pitch for SW models, enhanced line-lay shape when winding onto the spool, and a 2-speed oscillation system that adjusts pitch during spool reciprocation.
This well-considered mechanism enhances line release and trouble-free performance.
The benefits extend beyond stable casting and longer distance, contributing to smooth line release in vertical jigging.
Even in conditions with strong currents or heavy jigs, it minimizes line entanglement and friction, quickly delivering metal jigs to the desired depth.
After hooking a fish, it maintains steady drag pressure with minimal line tension fluctuation to subdue powerful pulls from monsters.


INFINITYXROSS

Enhanced Gear Strength and Durability—The Core of SW



Thanks to advancements in gear surface design and manufacturing, Infinity Xross expands the contact surface between drive and pinion gears.
This disperses load on the gear surface to prevent concentrated damage, thereby improving durability.
The NEW STELLA SW features a gear width about 1.3 times wider than the previous model, maintaining smooth gear feeling even under higher loads.


ANTI-TWIST FIN

Suppress Unwanted Line Trouble



A fin placed near the line roller reduces line slack, preventing the line from slipping under the spool skirt.
Elastic material in the fin also prevents damage when knots are reeled in.
Includes Fin B for creating a gap as in the previous design.


AR-C Spool



The AR-C Spool, with a specially shaped spool ring, smooths line flow and improves both line trouble prevention and long-casting performance.
The 25 STELLA SW uses a newly shaped AR-C with a ring color designed to prevent line from catching.
In harsh SW games, the spool ring can endure unexpected loads.
The surface is treated with a high-durability wear-resistant barrier coating to enhance durability.
It also reduces line damage, maintains a smooth surface longer, and remains less prone to scratches.
If scratched, the ring alone can be replaced through SHIMANO After Service.*


X PROTECT & X SHIELD

Impenetrable Waterproof Structure



One of the greatest threats in SW games is saltwater intrusion.
Once inside the reel, seawater corrodes metal parts, significantly degrading initial performance.
STELLA SW features thorough sealing on the body, drag knob, and line roller to block water entry.
The body and stopper section have achieved IPX8 waterproofing standard.
This delivers high reliability and durability under extreme saltwater conditions.
The waterproof structure has also been refined to preserve waterproofing while enabling smoother rotation.
It achieves the contradictory elements of high waterproof performance and silky rotation.



Waterproof structure is also applied to the handle knob.




Newly Designed Drag Knob for Improved Operability





With every part of the STELLA SW refined for detail, the drag knob has been enlarged by approximately 25% to improve operability.
This makes it easier to grip quickly and allows for more precise fine-tuning.
This brings an advantage in swiftly tightening or loosening the drag when fighting big fish.


Lightweight & Compact Rotor Exclusive for 8000 Size





The rotor is a high-rigidity X-Rigid Rotor designed exclusively for the 8000 size.
It's about 5mm more compact than the 10000 size, and together with the spool, is approximately 50g lighter.
This reduction in inertia enhances casting and significantly improves jigging operability and comfort.
Its size and usability make it an ideal match for rock shore and offshore casting or jigging with PE3–4 lines.


Infinity Connect Aims for “Ultimate Casting Performance”



The NEW STELLA SW was designed from the ground up under SHIMANO’s Infinity Connect concept to perfectly match with the NEW Ocea Plugger Limited and Ocea 17+ PE.
Combining these systematically developed reels, rods, and gear dramatically enhances total casting performance, offering three key benefits: improved casting feel, increased casting distance, and higher line strength retention.
This synergy accelerates the overall potential of the tackle, delivering a clear advantage in offshore casting.


It’s About Pursuing the Essence



Reels, rods, and gear developed by thoroughly exploring the elements demanded in fishing.
Combining these with clear intent creates synergy, delivering greater benefits to anglers—this is the design philosophy of “Systematic Product.”
It is SHIMANO, a comprehensive developer of all fishing gear, that can realize Infinity Connect.
Toward a new dimension in fishing.

2025 OFFSHORE CASTING CONCEPT

Aiming for the “Ultimate Casting Performance”



In 2025, the first release of the Infinity Connect concept was the Offshore Casting Concept.
What lies at its core?
Fishing involves various actions—casting, enticing, fighting...
Among these, Infinity Connect’s Offshore Casting Concept thoroughly pursues performance enhancements with a specific focus on “casting.”
This brings anglers three distinct benefits:
Improved casting feel, increased casting distance, and enhanced line strength retention.
These three advantages define its value.


REEL





With Infinity Loop installed in the STELLA SW, line release resistance is reduced.
The denser line winding compared to previous models enables resistance-free casting.


ROD





The X Guide Touch-Free Titanium equipped in the Ocea Plugger Limited minimizes blank contact.
It was meticulously designed to perfectly match SHIMANO reels sized 8000 to 14000.
Height, angle, and axis alignment of the reel are analyzed so that the guides line up seamlessly along their extension.


GEAR





Adopting SHIMANO’s first-ever 16-strand structure, a new configuration includes one core strand to reduce flattening and deformation.
The surface is treated for ultimate smoothness and uniformity, while its ideal stiffness ensures smooth line release.

Together, these products form a casting game environment at an unprecedented high level.


The Sound and Release Are Different—Experience Unmatched Casting Feel


*Based on SHIMANO testing

The first surprise with Infinity Connect is its casting quietness.
With lines densely wound on the 25 STELLA SW, they are guided by the high-foot X Guide Touch-Free Titanium to draw an ideal trajectory far from the blanks.

Traditional setups produced flapping sounds and unpleasant vibrations as lines hit the blanks during release.
But Infinity Connect significantly reduces this interference, letting the line pass through guides with only a pleasant whistling sound, launching smoothly without deceleration.

It feels like using a lighter class of tackle.
The line seems thinner due to the frictionless feel.
The light and seamless casting sensation itself excites the angler’s instincts and may transform even demanding offshore casting into pure enjoyment.


Witness the Casting Distance




*Based on SHIMANO testing

In casting games, distance is power.
The farther you can cast a lure, the greater the possibilities.

Infinity Connect extends casting distance by approximately 5% compared to previous setups.
For anglers who regularly cast 80m, each cast can now reach about 4m farther.
With games like GT or yellowtail that involve over 200 casts per day, this results in a total of 800m more lure coverage.
In such games, this advantage is immense.

Conversely, achieving the same distance with 5% less input reduces fatigue and increases accuracy.
In tuna games targeting bait boils at long range and situations requiring sustained performance over time, this benefit is invaluable.

Distance Measurement Test Tackle Setup

Infinity Connect
REEL: NEW STELLA SW 14000XG
ROD: NEW OCEA PLUGGER LIMITED S83H
GEAR: OCEA 17+ PE #8
LURE: Ocea Pencil Custom Hiramasu 220F

Conventional Setup
REEL: 19 STELLA SW 14000XG
ROD: 21 OCEA PLUGGER LIMITED S83H
GEAR: OCEA 8 PE #8
LURE: Ocea Pencil Custom Hiramasu 220F


Improved Line Strength Retention Supporting Continuous Casting




*Based on SHIMANO testing

The tackle setup under the Infinity Connect philosophy reduces contact between line and blanks, significantly mitigating PE line wear.
A field test comparing surface wear and strength after 200 casts showed a clear reduction in fiber fraying compared to conventional tackle.
Strength testing also demonstrated sustained initial tensile strength.

Line strength retention improved by approximately 20% compared to previous setups, not only for the main line but especially around the PE-to-leader knot area, where damage is most likely.

Preventing line wear and maintaining strength directly increases landing rates for big fish, while also reducing the time spent on line replacement or system rebuilding.
It supports continuous casting, helping anglers avoid missed strikes.
Staying focused on the game ultimately contributes to better results.

While 2025 marks the first release of the offshore casting concept combining STELLA SW, OCEA PLUGGER LIMITED, and OCEA 17+, further projects are already underway.
The scope extends beyond offshore categories.

Infinity Connect proposes “a world beyond.”
Combining rods, reels, and gear developed with clear intent creates synergy that surpasses using each item independently, offering even more benefits to anglers.


Features



X-Rigid Rotor
Made from aluminum alloy and carefully analyzed in 3D to optimize wall thickness and placement, achieving greater rigidity, durability, and rotational balance than ever before.
This high rigidity contributes to improved drag and other functions.




X-Rigid Handle
A cold-forged, high-rigidity handle designed exclusively for STELLA SW to transmit angler power without loss.




High-Rigidity Arm Cam
To boost rigidity, a metal arm cam (like the rotor) is used, transmitting STELLA SW's power accurately during heavy line retrieval or drag runs.
The metal plating maintains a smooth surface over time and minimizes line damage.




STELLA SW Exclusive Line Roller
DLC (Diamond-Like Carbon) coating reduces friction and prevents line wear.
It also features a contact-type waterproof seal to block seawater intrusion at the line roller, protecting internal bearings.
Durability is improved more than 10-fold compared to models without this feature.* Based on SHIMANO testing.




Line Roller Loosening Prevention Mechanism
The line roller, which absorbs the first force from large fish, includes a mechanism to prevent loosening.
Bolts securing the line roller are double-locked with set screws to keep them secure.




CI4+ Handle Knob (Excludes 14000)
Features a carbon CI4+ handle knob balancing high rigidity and light weight.
(The 14000 size uses a lightweight hollow oval round knob.)
