[SHIMANO] Genuine Spare Parts for 14 Scorpion 200 HG Product code: 032256 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 14 Scorpion 200 HG Product code: 032256 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 [Regular Price: US$1.10]

Prices vary according to options.

View availability
Part Number:
Quantity:
Contact Us

Item Description

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.


- Genuine Spool Purchase

* If you just want the genuine spool (No.76 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/phone/product/1974

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* As for the "30 / ROLLER CLUTCH" , they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
1 103EE FIXING BOLT 2.75
2 10Q5Q RETAINER 3.85
3 10FFB HANDLE FIXING NUT 2.75
4 13MAA HANDLE CAP 3.85
5 103E9 FIXING BOLT 1.10
6 10PXY HANDLE GRIP BUSHING (B) 1.65
7 104FH WASHER 2.20
8 13V07 HANDLE KNOB 11.55
9 104VX BALL BEARING (4 X 7 X 2.5) 13.75
10 13HRE HANDLE 22.55
11 13HY6 HANDLE ASSEMBLY 67.65
12 10KXV STAR DRAG CLICK PLATE 1.65
13 10J26 STAR DRAG CLICK PLATE 1.65
14 10BT0 CLICK PIN 1.65
15 10BT2 CLICK SPRING 1.65
16 10ATY STAR DRAG 17.05
17 10A70 STAR DRAG SPRING 2.75
18 10A3T STAR DRAG FIXING NUT 3.85
19 10J1N STAR DRAG SPACER 1.65
20 10D60 MAIN GEAR WASHER (C) 1.65
21 13TXR MECHANICAL BRAKE KNOB 9.35
22 10896 MECHANICAL BRAKE WASHER 1.10
23 1085F MECHANICAL BRAKE WASHER 1.10
25 105C0 BALL BEARING (3 X 10 X 4) 13.75
26 10EYS BEARING SPACER 2.75
28 10MPT FIXING BOLT 1.10
30 10F5D ROLLER CLUTCH BEARING A-RB *Cannot be ordered 17.05
31 10CCN INNER TUBE 6.05
32 10D3H STAR DRAG PLATE 2.75
33 106XT STAR DRAG WASHER 6.05
35 10CHF STAR DRAG WASHER 6.05
36 109BB STOPPER GEAR 6.05
37 1058L DRIVE GEAR SHAFT 11.55
38 10HJG WORM SHAFT GEAR PINS 1.65
39 10J47 WORM SHAFT GEAR 2.75
40 10MT0 FIXING BOLT 1.10
41 109T0 MAIN GEAR SHAFT FIXING PLATE 2.75
42 10C47 MAIN GEAR SHAFT WASHER 1.10
43 105NK E TYPE STOP RING 2.5 1.10
44 13S6U LEVEL WINDING GUARD 6.05
45 10FJB LEVEL WINDING RECEIVER 1.65
46 10CFW ADJUSTMENT WASHER SET 1.10
47 10FFZ WORM SHAFT PIN 2.75
48 108WQ O-RING 1.65
49 10NVQ LEVEL WINDING ASSEMBLY 11.55
50 10FNV WORM SHAFT GEAR 2.75
51 10AEZ WORM SHAFT PIN 1.10
52 104SN WORM SHAFT 6.05
53 10NFQ LEVEL WINDING PIPE 1.65
54 103DC FIXING BOLT 1.10
56 10487 CLUTCH YOKE SPRING 1.10
57 1046V CLUTCH YOKE 1.65
58 10LVE FIXING BOLT 1.10
59 10F3X CLUTCH CAM PUSH PLATE 3.85
60 10K0N CLUTCH CAM 2.75
61 10MME CLUTCH CLAW 3.85
62 104CN CLUTCH CLAW SPRING 1.65
63 10QGH CLUTCH PLATE 4.95
64 103C0 FIXING BOLT 1.10
65 10EX8 BALL BEARING (8 X 12 X 3.5) 13.75
66 10BVL BODY A SEAT 3.85
67 105NB E TYPE STOP RING 1.5 1.10
68 13FWV FRAME 50.60
69 1096S CLUTCH LEVER RECEIVER (B) 1.65
70 10CDL CLUTCH LEVER 6.05
71 10QSE LEVEL-WIND GUIDE 1.65
72 10FJZ WASHER 1.10
73 105NC E-TYPE RETAINING RING 2 1.10
74 108SK CLUTCH LEVER WASHER 1.10
75 108PY FRAME CONTACT WASHER 1.65
76 13GHJ SPOOL ASSEMBLY 56.10
77 1046G BRAKE SHOE (M) RED 1.10
78 10GEW BEARING RETAINING CLAMP 1.10
79 1057S SPOOL SHAFT CONTACT (B) 1.10
80 10EXQ BRAKE PIPE GEAR 13.75
81 103N4 FIXING BOLT 1.10
82 10F0N FRAME B RECEIVER ASSEMBLY 13.75
83 104MZ BODY B CAM LEVER ADJUSTMENT WASHER 1.65
84 10BAK BODY B CAM LEVER 2.75
85 10KNG DAMPER SPRING 1.10
86 103LE FIXING BOLT 1.10
87 10GFB CAM LEVER ADJUSTMENT WASHER 1.10
88 10AZB BR KNOB 3.85
89 103L7 FIXING BOLT 1.10
90 10CLF INTERMEDIATE GEAR 1.65
91 13R3L BODY B ASSEMBLY 11.55
92 105BP BALL BEARING (5 X 9 X 3) 13.75
93 10JDY WORM SHAFT GEAR SPRING 1.65
94 10TMT MECHANICAL BRAKE YURUMI STOP SPRING 1.65
95 10LCT FIXING BOLT 1.65
121 13TQZ MAIN UNIT A 22.55
122 10CMC DRIVE GEAR 22.55
123 10CRW PINION GEAR 11.55
BNKI 13WKD EXPLODED VIEW (ACCESSORIES) 1.65
OIL1 10LQ0 B-100 OIL (4.5G) 3.85
TRST 13VN4 INSTRUCTION MANUAL (ACCESSORY) 1.65
