[Avail] ABU Microcast Spool for OLD Ambassadeur 5000C/5001C [AMB5030R-C]

| Model Name

Microcast Spool AMB5030R-C (Spool Rim Depth: 3.0mm)


| Product Introduction



This is a Microcast Spool for the Old ABU Ambassadeur 5000C.

It is compatible with the ABU Ambassadeur 5000C and 5001C.

Production of the 5000C is believed to have started around 1967.
This spool is compatible with models produced from the earliest versions through approximately 1984, including those reissued by EBISU FISHING.
The 5001C version is compatible with models manufactured from approximately 1972 to 1981.

Later reissue models of both the 5000C and 5001C (manufactured by Mamiya-OP) feature a bulged handle-side side plate and are not compatible.

Although they share the same model name, this spool is not compatible with Palming models or ULTRACAST models. Please ensure you select the correct model.




Compatible reels use the spool shaft shape shown in the photo.

The cog wheel has been removed from the spool on the right. Remove the cog wheel and check the shape of the concealed section before purchasing.


| Features

By reducing both spool weight and line capacity, the total rotating mass is significantly decreased.
This greatly improves the minimum lure weight that can be cast while also increasing casting distance with lures of the same weight.


| How to Use



Remove the Genuine cog wheel from the Genuine spool and transfer it to the Microcast Spool.


| Color



Black


| Specifications

[Basic Specifications]

- Material
Spool: Super Duralumin (Anodized Finish)
Shaft: Stainless Steel

- Weight
Microcast Spool AMB5030R-C: 16.0g
Genuine Spool Ambassadeur 5000C (62172): 24.9g

- Compatible Reels
ABU Ambassadeur 5000C (Models from the Earliest Production Through the EBISU Period)
ABU Ambassadeur 5001C (Models Manufactured from 1972 to 1981)
Other models compatible with spool part number #8583

*Another model is available for reels manufactured after 1986 and for later 5001C models.
*ULTRACAST and Palming models are not compatible.


[Line Capacity]

12lb (φ0.285mm): 75m
14lb (φ0.310mm): 60m
16lb (φ0.330mm): 45m

The above values were measured using Yamatoyo Tegusu Co., Ltd. nylon line (Versatile Design), wound to the bottom of the spool rim.


| Attention

*If you apply thumb pressure directly to the spool rim, friction may cause the anodized finish to wear off.
Please apply thumb pressure only to the line-wound surface of the spool.
