Item Description

Special order item: ships in about 5 business days. This item is ordered from the manufacturer after your order is placed.

LIVRE SB 55-60 Balancer Handle mounted on a baitcasting reel

Refined Design and an Original Concept

LIVRE SB 55-60 removable balancer plate: main plate, bolt, tungsten weight, balancer plate, variable plate and center nut

S.B.S: Removable Balancer Plate

The Select Balancer System, which lets you attach and remove the balancer plate, has been renewed.
The main plate and the balancer plate are machined from A7075 extra super duralumin and fit together with remarkable precision.
The balancer plate is held by a single bolt, so it is easy to attach and remove.

LIVRE SB 55-60 quick slide balancer system with a tungsten weight

Q.S.B: Quick Slide Balancer System

The balancer weight is made of tungsten.
With the Quick Slide Balancer System, you loosen the screw with your fingers, slide the weight and fix it in any position, no tools needed.
The small weight (11.5g) comes as standard.

Positioning Marker

Markers laser-engraved on the side of the balancer plate serve as a guide for weight adjustment.
You can easily see where to set the balance weight for the best balance.

LIVRE SB 55-60 variable pitch system: short pitch and long pitch settings

V.P.S: Two Pitch Settings

Rotating the variable plate 180 degrees gives two pitch settings: 55mm and 60mm.
For example, use the short pitch setting for light lures or quick reeling, and the long pitch setting for heavy lures or slow reeling.
One reel gains two different characters.

LIVRE EP 37 thin-walled hollow titanium knob

Thin-Walled Hollow Titanium Knob EP 37

Designed with the focus on reeling and quick action, pursuing a shape that is easy to hook your fingers on and hard to slip off.
After field-testing many prototypes differing by a single millimeter, LIVRE arrived at 37mm.
The titanium wall thickness is set at 0.6mm.
It is a light, highly sensitive thin-walled hollow titanium knob with the ideal shape and feel for two fingers.

LIVRE SB 55-60 balancer parts: short and long balancer plates with large and small tungsten weights

Customizable Balancer Parts

The balancer plate pitch and the balancer weight can be customized.
Balancer plates come in long and short types, and balancer weights in large and small sizes, which you can combine.
So even when you customize the titanium knob with EASY CUSTOM, you can choose a tungsten weight that suits the knob weight and build a custom handle with a finely tuned balance.
SB 55-60 comes with the short type balancer plate and the small (11.5g) weight as standard.

Custom Titanium Knob Weights
Fino Plus	Fortissimo	EF 30	EP 37	EP 41
11.9g	15.5g	14.4g	14.5g	15.6g
EP 40	EP 44	EP 50	PT 48	PT 52
28.7g	31.4g	36.6g	33.6g	37.0g

* SB 55-60 comes with the small (11.5g) tungsten weight as standard.
* The balance can be finely tuned by combining the titanium knob and tungsten weight, the handle pitch, the balancer plate pitch and the position of the balancer weight.

LIVRE SB 55-60 EASY CUSTOM parts diagram: balancer weight, balancer plate, center nut, main plate, titanium knob, aluminum knob collar, knob end cap

LIVRE SB 55-60 EASY CUSTOM parts diagram: balancer weight, balancer plate, center nut, main plate, titanium knob, aluminum knob collar, knob end cap

LIVRE SB 55-60 color variation chart with 7 main plate and center nut color combinations

LIVRE SB 55-60 Balancer Handle mounted on a baitcasting reel, large photo

[Color Variation] *Click an image to enlarge.

Gunmetal/Gold	Gunmetal/Titanium	Titanium/Gold

Titanium/Red	Gunmetal/Red	Gunmetal/Blue

Titanium/Blue

[Knob Type Selection] *Standard: EP 37 (Fire). Choose the knob in the cart.

EP 37 (Standard)	Fino Plus	EF 30

PT 35	EP 41	EP 44

PT 42	PT 48	TB-S
[Knob Color Selection] *Color samples are PT 48. Available colors differ by knob.

Fire	Brown (IP)

Model	Titanium Knob	Handle Type	Center Nut	Pitch (mm)	Weight (g)	Product No.	Item No.
SB 55-60	EP 37	SHIMANO M7	Right	55-60	51.9	SBA-56SR	857*
		SHIMANO M7	Left		51.9	SBA-56SL	858*
		DAIWA/Abu/SHIMANO M8	Right		51.4	SBA-56DR	861*
		DAIWA/Abu/SHIMANO M8	Left		51.4	SBA-56DL	862*
		DAIWA B1 (Bolt Type)	Left and Right		52.6	SBA-56B1	859*

* Weights are with the standard knob (EP 37).
* For Item No. marked with “*”, refer to the Item No. in the Color Combination table.
* SHIMANO OCEA CONQUEST 300 size and larger fit the DAIWA/Abu type. See the compatibility chart for details.

Main Plate	Titanium Knob	Center Nut	Aluminum Knob Collar	Knob End Cap	Item No.
Gunmetal	Fire	Gold	Gold	Gunmetal	1
Gunmetal		Titanium	Titanium	Gunmetal	2
Titanium		Gold	Gold	Titanium	4
Titanium		Red	Red	Titanium	6
Gunmetal		Red	Red	Gunmetal	7
Gunmetal		Blue	Blue	Gunmetal	8
Titanium		Blue	Blue	Titanium	9

Check LIVRE handle compatibility with your reel and how to select the handle type

* Specifications and prices on this page are subject to change without notice.
* We try to show product colors as accurately as possible, but actual colors and materials may look slightly different depending on photography and your screen.
