[Avail] SHIMANO Microcast Spool MT05XT25 / MT05XT39 for 05 Metanium XT

[Avail] SHIMANO Microcast Spool MT05XT25 / MT05XT39 for 05 Metanium XT

Our Selling Price: US$56.17 [Regular Price: US$80.24]

Prices vary according to options.

Spool depth:
Color:
Brake system:
Quantity:

Item Description

 Regarding the stock of AVAIL product

It takes us two to three days to get ready to send Avail products
because we order them from the Avail factory.
Sometimes they might be out of stock at the timing of your order.
In the case of a stockout, we refund your purchase price immediately.

 Type and description

Metanium
Avail Microcast Spool MT05XT25
(The spool rim level is 2.5mm)
Avail Microcast Spool MT05XT39
(The spool rim level is 3.9mm)

Metanium XT
This model is for '05 Metanium XT.
The diameter is φ34mm (same as Metanium Mg).
You can use a genuine centrifugal brake and also magnetic brake "Microcast Brake SHSC-05A".

 Spool colors

Metanium XT
・BLACK
・NAVY
・RED
・PURPLE
・ORANGE
・GUNMETAL


 Braking system options

Metanium XT

With No brake
※When you just remove SVS from your genuine spool and use it, please choose here.
At the most reasonable price, you can try the performance of lightweight spool.

Metanium XT

With 4P centrifugal brake
※ It is lightweight exclusive brakes and you can easily attach it.
Since it is manufactured more lightly (about 0.3g loss in quantity) than a genuine SVS unit, the spool gross weight also becomes still lighter.

Metanium XT

With a magnetic brake
※ Although the attachment would be difficult, fine tuning of the magnetic brake is possible even with SHIMANO reel.

Spec

|Material


Spool : extra super duralumin
Shaft : stainless-steel

|Compatibility

'05 Metanium XT

|Weight

Microcast Spool MT05XT25 : 8.9g
(The weight ratio against genuine product approximately 73%)
Microcast Spool MT05XT39 : 8.1g
(The weight ratio against genuine product approximately 67%)

SHIMANO genuine spool : 12.1g

※The numerical values mentioned above are the result of measuring with SVS unit.

|Line capacity

MT05XT25 12Lb-55m:10Lb-65m:8Lb-85m
MT05XT39 14Lb-75m:12Lb-90m:10Lb-105m:8Lb-135m

※The numerical value mentioned above is the result of measuring by winding nylon line up to the edge of spool rim.


 Instruction Manual

|How to replace genuine SVS


Metanium XT
To remove the SVSunit off the spool

The unit is press-fitted tightly.
Pull the unit by holding the 3 part protruding from the unit, little by little with patience.
(Please take great care not to damage SVS and scratch spool.)

| How to use 4-points centrifugal brake
(Although you need to purchase the brake separately, the replacement is very easy.)

Metanium XT

Just attach the centrifugal brake purchased to the spool with no difficulty.
You can use the genuine Shimano brake blocks.

This choice will be nice if you are concerned about pulling up SVS from a genuine spool.
And it will be also convenient if you do not want to remove SVS unit because you want to use the genuine spool as a spare.

|How to use the magnetic brake

Metanium XT

Attach the brake on the receiver as pictured above.
Turn the screw to adjust the brake.
When the distance between the magnetic pole face and the bottom-face of spool inside gets closer, the brake becomes stronger.
